SU BAZLI BOYA SİSTEMLİ
Su Bazlı Boya Sistemli Karton Ambalaj Baskı Makinesi taramalı oluklu mukavva yazıcısı, dijital mürekkep püskürtmeli baskı teknolojisini benimser. Kalıp yapımına gerek yoktur, tek parça baskı yapılabilir. Çevre dostu su bazlı mürekkep kullanır. Maksimum baskı genişliği 2500 mm’ye kadar ulaşabilir, uzunlukta herhangi bir sınırlama yoktur. Temel baskı hassasiyeti 600 dpi’ye kadar çıkar, baskı hızı saatte 600 metreye kadar ulaşabilir. Kullanım maliyeti düşüktür, maliyet etkinliği yüksektir. Kişiselleştirilmiş ve özelleştirilmiş küçük ve orta ölçekli siparişler için uygundur.
| Product Name | Scanning Corrugated Cardboard Printer |
|---|---|
| Product Model | RS2500-S-E8 |
| Printhead Type | Micro piezoelectric high-precision Epson i3200 A1 printhead |
| Printhead Quantity | 8 units |
| Color Model | CMYK |
| Ink Type | Special water-based dye ink, Special water-based pigment ink |
| Printing Format | Auto feeding below 2500mm*1350mm, manual feeding 2500mm*unlimited length |
| Printing Speed | Around 300–600㎡/hour |
| Medium Distance | 2mm–4mm |
| Printing Resolution | ≥360*600dpi |
| Drying Speed | Liner-board can be dry once print out |
| Working Environment | 20–25℃ Indoor, Humidity 50–70% |
| Ink Supply | Automatic ink supply |
| Feeding Mode | Automatic leading edge feeding, default pressure roller platform, solution platform can be customized |
| Material Thickness | 3mm–40mm (or as customized) |
| Operate System | Professional RIP system, professional printing system, Win7 system with 32 bit operating system or above |
| Power Supply | About 20KW power: AC380 ±10%, 50–60HZ |
| Machine Dimension | 4920*3107*2195mm |
| Weight | 3500 KGS |
| Warranty | 12 months exclude the consumables |
Long-lasting stable printhead, high precision, high saturation, color bright, variable ink drop technology to achieve multi-grayscale printing
The whole operation process intelligentization, no need for plate making, plate exposure and repeated color matching
Automatic feeding with accurate positioning, less errors, lower noise and run smoothly, suit for single sheet and multi-sheet feeding
Adopt fully automatic deviation correction scheme, reasonable air suction space design, materials are firmly adsorbed
Precise positioning, achieve optimal control of stepping precision, higher precision, faster speed and more stable performance
The sun wheel pressure roller assistance to ensure the material is flat and prints well
