XMAY 2016
✔ Özel Dijital Varak baskı sistemi ile polyester kumaşlara aynı anda hem renkleri hem de parlak altın, gümüş ve farklı renklerdeki varak baskıları yapabileceksiniz.
✔ 16 adet Epson i3200 model baskı kafası ile 120m/saate varan baskı hızına ulaşırsınız.
✔ 10.000 metre tek parça Jumbo kağıt besleme sistemi ile zamandan ve fireden tasarruf edin.
✔ Hızlı ve güçlü 2 farklı yönde mevcut olan kurutma sistemi sayesinde baskı sonrasında varak filminiz kırışmaz ve sarım esnasında boya ıslak kalarak leke yapmaz.
✔ Güçlendirilmiş kurutma sayesinde varak film üzerinde mükemmel kurutma sağlanır. Bu kurutma sayesinde varak uygulamalarınız mükemmel yapışma kalitesine ve yüksek yıkama haslığına sahip olur.
| Model | X-1908 IP | X-2016 IP | X-2024 IP | X-2036 IP |
|---|---|---|---|---|
| Printing Size | 1900MM | 2000MM | 2000MM | 2000MM |
| Print Head | EPSON I3200-A1 | |||
| Print Head Quantity | 8 PCSs | 16 PCS | 24 PCS | 36 PCS |
| Printing Speed | 1pass: 330㎡/h | 1pass: 650㎡/h | 1pass: 900㎡/h | 1pass: 1250㎡/h |
| Media Type | Sublimation paper | |||
| Heating System | Automatic thermostat dryer | Four groups of high-power drying | ||
| RIP Software | Riprint / Montana / Neostampa | |||
| Cleaning Function | Siphonmode / positive pressure inking mode | |||
| Operation Environment | Temperature: 20–30°C, Humidity: 45–65% | |||
| Power Supply | AC220V, 50Hz | |||
| Power Requirements | 1800W / 2400W | 4800W / 12000W | 6400W / 14000W | |
| Printer Dimension | 3500×1350×1800mm | 4100×2100×1800mm Feeding system: 2330×1350×1100mm | ||
| Printer Weight | 900KG | 1600KG + feeding/discharge: 460KG | ||
| Maximum Width | 1800mm |
|---|---|
| Rated Power | 8.5kw |
| Product Dimension | 1955×2300×1120mm |
| Net Weight | 495kg |
| Power Source | AC 220V, 50/60Hz |
| Working Power Consumption | 5.6KW/h |
| Package Dimension | 2360×2540×1290mm |
| Gross Weight | 660kg |
| Printing Size | 1900MM |
|---|---|
| Print Head | EPSON I3200-A1 |
| Print Head Quantity | 8 PCS |
| Printing Speed | 1pass: 330㎡/h |
| Media Type | Sublimation paper |
| Heating System | Automatic thermostat dryer |
| RIP Software | Riprint / Montana / Neostampa |
| Cleaning Function | Siphonmode / positive pressure inking mode |
| Operation Environment | Temperature: 20-30 °C, Humidity: 45-65% |
| Power Supply | AC220V, 50Hz |
| Power Requirements | Machine power: 1800W External drying: 2400W |
| Printer Dimension | 3500×1350×1800mm |
| Printer Weight | 900KG |
| Printing Size | 2000MM |
|---|---|
| Print Head | EPSON I3200-A1 |
| Print Head Quantity | 16 PCS |
| Printing Speed | 1pass: 650㎡/h |
| Media Type | Sublimation paper |
| Heating System | High-power drying |
| RIP Software | Riprint / Montana / Neostampa |
| Cleaning Function | Siphonmode / positive pressure inking mode |
| Operation Environment | Temperature: 20-30 °C, Humidity: 45-65% |
| Power Supply | AC220V, 50Hz |
| Power Requirements | Machine power: 4800W External drying: 12000W |
| Printer Dimension | 4100* 2100*1800 MM, 10000m feeding and discharging system size: 2330*1350*1100 MM |
| Printer Weight | 1600KG 10000m feeding and discharging system weight: 460KG |
| Printing Size | 2000MM |
|---|---|
| Print Head | EPSON I3200-A1 |
| Print Head Quantity | 24 PCS |
| Printing Speed | 1pass: 900㎡/h |
| Media Type | Sublimation paper |
| Heating System | High-power drying |
| RIP Software | Riprint / Montana / Neostampa |
| Cleaning Function | Siphonmode / positive pressure inking modee |
| Operation Environment | Temperature: 20-30 °C, Humidity: 45-65% |
| Power Supply | AC220V, 50Hz |
| Power Requirements | Machine power: 6400W External drying: 14000W |
| Printer Dimension | 4100* 2100*1800 MM, 10000m feeding and discharging system size: 2330*1350*1100 MM |
| Printer Weight | 1600KG 10000m feeding and discharging system weight: 460KG |
| Printing Size | 2000MM |
|---|---|
| Print Head | EPSON I3200-A1 |
| Print Head Quantity | 36 PCS |
| Printing Speed | 1pass: 1250㎡/h |
| Media Type | Sublimation paper |
| Heating System | High-power drying |
| RIP Software | Riprint / Montana / Neostampa |
| Cleaning Function | Siphonmode / positive pressure inking mode |
| Operation Environment | Temperature: 20-30 °C, Humidity: 45-65% |
| Power Supply | AC220V, 50Hz |
| Power Requirements | Machine power: 6400W External drying: 14000W |
| Printer Dimension | 4100* 2100*1800 MM, 10000m feeding and discharging system size: 2330*1350*1100 MM |
| Printer Weight | 1600KG 10000m feeding and discharging system weight: 460KG |
| Maximum Width | 1800mm |
|---|---|
| Rated Power | 8.5kw |
| Product Dimension | 1955×2300×1120mm |
| Net Weight | 495kg |
| Power Source | AC 220V, 50/60Hz |
| Power Consumption | 5.6KW/h |
| Package Dimension | 2360×2540×1290mm |
| Gross Weight | 660kg |
