Kumaş Baskı Makinesi

XMAY RTR XR2064

Direkt Kumaş Baskı Makinesi

✔ Yüksek çözünürlüğe sahip Ekonomik ve Endüstriyel tip baskı kafaları.(Epson I3200, Ricoh G5/G6, Kyocera)

✔ 4, 6 ve 8 renk baskı modu seçenekleri; en özel renklerin yüksek kalitede basılmasını sağlar

✔ Pamuk, keten, ipek, yün, naylon, polyester ve non woven tarzı örme yada dokuma tüm kumaşların üzerine direkt baskı yapabilmesini sağlayan,  kendini yıkama özelliğine sahip Blanket sistemi.

✔ Tüm üretim süreci boyunca çevreye duyarlı, 3-4 renk haslığı, harika tuşe hissi veren natürel kumaş dokusuna zarar vermeyen boyalar.

✔ Reaktif, Pigment, Asit, Disperse boyalar ile baskı yapılabilir.

✔ Kalıp maliyeti olmadan düşük maliyetli ve istenildiği kadar renk seçeneği sunan , üretimlerde stok maliyetini kaldıran ve üretimlere hız katan profesyonel baskı çeşidi.

✔ Sirkülasyon sistemli boya akışı sayesinde kafalarda tıkanma yapmadan, uzun ömürlü yüksek performans

✔ Özel RIP yazılımı sayesinde doğru renk profilleri ile düşük boya maliyeti sağlanır.

✔ Negatif basınçlı mürekkep kontrol sistemi ve mürekkebin gaz giderme sistemi olan Degassing sistemi sayesinde mürekkep daha akıcı ve sorunsuz çalışacağından, yazıcı performansı artar ve baskı kabiliyeti , hızı yükselir.

Technical Parameters
Model XK20-32 XK20-48 XK20-64
Printerhead32 pcs Kyocera Print head (Single channel 600dpi)48 pcs Kyocera Print head (Single channel 600dpi)64 pcs Kyocera Print head (Single channel 600dpi)
Print Thickness2–30mm range is adjustable
Max. Printwidth2000mm / 3200mm2000mm / 3200mm2000mm / 3200mm
Max. Fabric Width2000mm / 3200mm2000mm / 3200mm2000mm / 3200mm
Production Speed460㎡/h690㎡/h920㎡/h
Image TypeJPEG/TIFF/BMP file format,RGB/CMYK color mode
Ink ColorTen colors optional: C M Y K LC LM Grey Red Orange Blue
Types of InkReactive / Disperse / Pigment / Acid ink
RIP SoftwareNeostampa / Wasatch / Texprint
Transfer MediumBelt continuous transport, automatic fabric winding / unwinding system
Fabric TypeKnitted or woven cotton, linen, Silk, wool, chemical fiber, nylon etc.
Power16KW16KW16KW
Power Supply380VAC, Three phase five wire
Compressed AirGas flow after accuracy 0.3m3/min, air pressure p 6 kg
Working EnvironmentTemperature: 18–28°C, Humidity: 50%~70%
Width2000MM / 3200MM2000MM / 3200MM2000MM / 3200MM
Overall Dimensions4200x3800x 2000mm / 5600x3800 x2000mm4200x4200x 2000mm / 5600x4200 x2000mm4200x4300x 2000mm / 5600x4300x 2000mm
Weight4500KG / 5700KG4900KG / 6100KG5200KG / 6500KG
Weight Oven750KG / 1050KG750KG / 1050KG750KG / 1050KG
Technical Parameters
XR2032
Printerhead: 32 pcs Kyocera Print head (Single channel 600dpi)
Print Thickness: 2–30mm range is adjustable
Max. Printwidth: 2000mm / 3200mm
Max. Fabric Width: 2000mm / 3200mm
Production Speed: 460㎡/h
Image Type: JPEG/TIFF/BMP file format,RGB/CMYK color mode
Ink Color: Ten colors optional: C M Y K LC LM Grey Red Orange Blue
Types of Ink: Reactive / Disperse / Pigment / Acid ink
RIP Software: Neostampa / Wasatch / Texprint
Transfer Medium: Belt continuous transport, automatic fabric winding / unwinding system
Fabric Type: Knitted or woven cotton, linen, Silk, wool, chemical fiber, nylon etc.
Power: 16KW
Power Supply: 380VAC, Three phase five wire
Compressed Air: Gas flow after accuracy 0.3m3/min, air pressure p 6 kg
Working Environment: Temperature: 18–28°C, humidity: 50%–70%
Width: 2000MM / 3200MM
Overall Dimensions: 4200x3800x 2000mm / 5600x3800 x2000mm
Weight: 4500KG / 5700KG
Weight Oven: 750KG / 1050KG
XR20-48
Printerhead: 48 pcs Kyocera Print head (Single channel 600dpi)
Print Thickness: 2–30mm range is adjustable
Max. Printwidth: 2000mm / 3200mm
Max. Fabric Width: 2000mm / 3200mm
Production Speed: 690㎡/h
Image Type: JPEG/TIFF/BMP file format,RGB/CMYK color mode
Ink Color: Ten colors optional: C M Y K LC LM Grey Red Orange Blue
Types of Ink: Reactive / Disperse / Pigment / Acid ink
RIP Software: Neostampa / Wasatch / Texprint
Transfer Medium: Belt continuous transport, automatic fabric winding / unwinding system
Fabric Type: Knitted or woven cotton, linen, Silk, wool, chemical fiber, nylon etc.
Power: 16KW
Power Supply: 380VAC, Three phase five wire
Compressed Air: Gas flow after accuracy 0.3m3/min, air pressure p 6 kg
Working Environment: Temperature: 18–28°C, humidity: 50%–70%
Width: 2000MM /3200MM
Overall Dimensions: 4200x4200x 2000mm / 5600x4200 x2000mm
Weight: 4900KG / 6100KG
Weight Oven: 750KG / 1050KG
XR20-64
Printerhead: 64 pcs Kyocera Print head (Single channel 600dpi)
Print Thickness: 2–30mm range is adjustable
Max. Printwidth: 2000mm / 3200mm
Max. Fabric Width: 2050mm / 3250mm
Production Speed: 920㎡/h
Image Type: JPEG/TIFF/BMP file format,RGB/CMYK color mode
Ink Color: Ten colors optional: C M Y K LC LM Grey Red Orange Blue
Types of Ink: Reactive / Disperse / Pigment / Acid ink
RIP Software: Neostampa / Wasatch / Texprint
Transfer Medium: Belt continuous transport, automatic fabric winding / unwinding system
Fabric Type: Knitted or woven cotton, linen, Silk, wool, chemical fiber, nylon etc.
Power: 16KW
Power Supply: 380VAC, Three phase five wire
Compressed Air: Gas flow after accuracy 0.3m3/min, air pressure p 6 kg
Working Environment: Temperature: 18–28°C, humidity: 50%–70%
Width: 2000MM / 3200MM
Overall Dimensions: 4200x4300x 2000mm / 5600x4300x 2000mm
Weight: 5200KG / 6500KG
Weight Oven: 750KG / 1050KG
