AVETEX D1250
| Model | D1250 Non-Stop UV PRINTER |
|---|---|
| Printhead | Industry Grade Ricoh GEN5/GEN6 head |
| Print Head Number | Max 8 heads |
| Color Set | CMYK; CMYK+W; CMYK+CMYK; CMYK+W+V |
| Print Width | Max 1.25m |
| Print Speed (G5 heads) | 4PASS 15 sqm/h 6PASS 12 sqm/h 8PASS 8 sqm/h |
| Print Speed (G6 heads, Maglev) | 4PASS 25 sqm/h 6PASS 20 sqm/h 8PASS 15 sqm/h |
| Print Direction | Unidirection/Bidirection |
| Media Type | Glass, Acrylic, Wood, Ceramic, Metal Sheet, PVC Sheet, Plastic, 3C product etc. |
| Media Thickness | Max. 100 mm |
| Ink Type | UV Curing Ink (None VOC) |
| Special Ink | Optional White Ink or Varnish |
| Curing System | LED Curing System |
| File Format | TIFF / JPEG / POSTSCRIPT3 / PDF |
| RIP Software | Riprint / Unitedfancy / Photoprint |
| Data Connector | USB3.0 |
| Power | 220VAC(±10%) Single Phase, 50/60 HZ |
| Power Consumption | 3.5 KW |
| Machine Size / N.W | 3.35m x 2.2m x 1.35m, 800kgs |
| Packing Size / G.W | 3.5m x 2.3m x 1.6m, 950kgs |
| Environment Requirement | Separated, clean, low dust, well-ventilated environment Working Temperature: 20℃–28℃ Relative humidity: 40%–60% |
